Pannello Slim Panel Basic G4

  • Famiglia di pannelli LED Slim economici, con versioni UGR < 19 adatte per illuminare gli uffici
  • Disponibili versioni dimmerabili DALI2
  • Efficienza fino a 130 lm/W
  • Versioni con interruttore CCT integrato per la selezione del colore (3000K-4000K) disponibili
  • 4 differenti potenze possibili (23/ 27/ 31/ 34 W)
  • Sostituzione diretta degli apparecchi convenzionali 4x18W o 2x36W
  • Sono disponibili accessori per l’installazione a incasso e a plafone
  • Adatto per applicazioni a incasso e a sospensione
Prodotti Accessoires
LEDPanelS-B4 Sq595-23/34W-830


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-3000K-IP40-UGR22

Product Code
542016014900
3000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-23/34W-840


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-4000K-IP40-UGR22

Product Code
542016014700
4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-23/34W-830-U19


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-3000K-IP40-UGR19

Product Code
542016014200
3000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-23/34W-840-U19


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-4000K-IP40-UGR19

Product Code
542016015700
4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Re295-23/34W-830


Slim Panel Basic G4 Re295-23|27|31|34W-2990|3510|4030|4420lm-3000K-IP40-UGR22

Product Code
542016015000
3000 K
130 lm/W
TL 2x36W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Re295-23/34W-840


Slim Panel Basic G4 Re295-23|27|31|34W-2990|3510|4030|4420lm-4000K-IP40-UGR22

Product Code
542016014500
4000 K
130 lm/W
TL 2x36W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Re295-23/34W-830-U19


Slim Panel Basic G4 Re295-23|27|31|34W-2990|3510|4030|4420lm-3000K-IP40-UGR19

Product Code
542016014800
3000 K
130 lm/W
TL 2x36W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Re295-23/34W-840-U19


Slim Panel Basic G4 Re295-23|27|31|34W-2990|3510|4030|4420lm-4000K-IP40-UGR19

Product Code
542016014600
4000 K
130 lm/W
TL 2x36W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-23/34W-830/840


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-3/4000K-IP40-UGR22

Product Code
542016013800
3000|4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-23/34W-830/840-U19


Slim Panel Basic G4 Sq595-23|27|31|34W-2990|3510|4030|4420lm-3/4000K-IP40-UGR19

Product Code
542016013400
3000|4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
23 - 34
4420
LEDPanelS-B4 Sq595-34W-DALI-830


Slim Panel Basic G4 Sq595-34W-4420lm-3000K-DALI-IP40-UGR22

Product Code
542016014400
3000 K
130 lm/W
TL 4x18W
Bianco RAL9003
34
4420
LEDPanelS-B4 Sq595-34W-DALI-840


Slim Panel Basic G4 Sq595-34W-4420lm-4000K-DALI-IP40-UGR22

Product Code
542016015500
4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
34
4420
LEDPanelS-B4 Sq595-34W-DALI-830-U19


Slim Panel Basic G4 Sq595-34W-4420lm-3000K-DALI-IP40-UGR19

Product Code
542016014100
3000 K
130 lm/W
TL 4x18W
Bianco RAL9003
34
4420
LEDPanelS-B4 Sq595-34W-DALI-840-U19


Slim Panel Basic G4 Sq595-34W-4420lm-4000K-DALI-IP40-UGR19

Product Code
542016015300
4000 K
130 lm/W
TL 4x18W
Bianco RAL9003
34
4420
LEDPanelS-B4 Re295-34W-DALI-830


Slim Panel Basic G4 Re295-34W-4420lm-3000K-DALI-IP40-UGR22

Product Code
542016013500
3000 K
130 lm/W
TL 2x36W
Bianco RAL9003
34
4420
LEDPanelS-B4 Re295-34W-DALI-840


Slim Panel Basic G4 Re295-34W-4420lm-4000K-DALI-IP40-UGR22

Product Code
542016013200
4000 K
130 lm/W
TL 2x36W
Bianco RAL9003
34
4420
LEDPanelS-B4 Re295-34W-DALI-830-U19


Slim Panel Basic G4 Re295-34W-4420lm-3000K-DALI-IP40-UGR19

Product Code
542016013000
3000 K
130 lm/W
TL 2x36W
Bianco RAL9003
34
4420
LEDPanelS-B4 Re295-34W-DALI-840-U19


Slim Panel Basic G4 Re295-34W-4420lm-4000K-DALI-IP40-UGR19

Product Code
542016013300
4000 K
130 lm/W
TL 2x36W
Bianco RAL9003
34
4420
No products found for filters
Filtro prodotti
LEDPanelRc2 Sq600-Surface-Kit-WH


Accessorio Apparecchi a incasso - Kit di superficie 610mm x 610mm - Bianco

Product Code
542098017600
Scatola per montaggio sporgente
LEDPanelRc2 Re300-Surface-Kit-WH


Accessorio Apparecchi a incasso - Kit di superficie 1211mm x 311mm - Bianco

Product Code
542098017700
Scatola per montaggio sporgente
LEDPanelRc Sq600-Frame-WH


Accessorio Apparecchi a incasso - Telaio 644mm x 644mm - Bianco

Product Code
542098009600
Telaio da incasso
LEDPanelRc Re300-Frame-WH


Accessorio Apparecchi a incasso - Telaio 1244mm x 344mm - Bianco

Product Code
542098009800
Telaio da incasso
LEDPanelRc-S-B2 Suspension-Kit


Accessorio Pannello Slim Panel Basic G2 - Kit di sospensione

Product Code
542003021700
set funi di sospensione
LEDPanelRc-S-B2 Mounting-Springs


Accessorio Pannello Slim Panel Basic G2 - Molle di montaggio

Product Code
542003021800
Kit di fissaggio
LEDPanelRc-S-B2 Re298 Mounting-Springs


Accessorio Pannello Slim Panel Basic G2 - Molle di montaggio 295mm x 1195mm

Product Code
542098033000
Kit di fissaggio
LEDFixture-Ceiling-Cable-Kit-0.5m


Accessorio Kit cavo di sicurezza a soffitto - 500mm - Acciaio inossidabile

Product Code
140060852
set funi di sospensione
LEDTrunking DALI Power Supply


Accessorio Trunking - Alimentazione DALI

Product Code
542098001000
Alimentazione intermedia
Junction-Box-WH


Accessorio Illuminazione per interni - Scatola di giunzione - Bianco

Product Code
542098030700
Giunto/raccordo diritto
LEDPanelRC-Sl U19 EM-kit 3h


Accessorio Apparecchi a incasso - Kit di emergenza 3 ore

Product Code
542098000900

Download

Familysheet_it_SlimP_B4.pdf
LDT_SlimP_B4.zip
