Waterproof EcoMax G4

LEDWaterproof-E4 L15-42/52W-840

Product Code
531000042700
  • Waterproof luminaire in "sealed-for-life" concept
  • Quick & easy installation due to twist-and-lock endcap
  • Standard equiped with Power switch
  • Supplied with vandal-proof stainless steel ceiling and suspension clips
  • Equipped with 3x2.5mm² throughwiring

Specifications

Electrical data

Nominal voltage 220|240 V
Voltage type AC/DC
Power factor 0.95
Max. system power 52 W
Max. number of luminaires per miniature circuit breaker B16 (MCB) 15
Max. number of luminaires per miniature circuit breaker C16 (MCB) 38
Surge protection 2 kV
With sensor No
Max. inrush current 33.1 A
Inrush time 168
Max. number of luminaires per miniature circuit breaker C10 (MCB) 23
Max. number of luminaires per miniature circuit breaker C13 (MCB) 30
Including emergency lighting No
Frequency 50|60 Hz
Nominal voltage DC 180|260 V

Photometrical data

Colour temperature 400 K
Equivalent to TL 1/2x58W
Colour consistency (SDCM) 4
Colour rendering index (CRI) > 80

Light technical data

Beam angle 120°
Beam angle 120°

Lifespan

Lifetime (L70) 100000 h
Lifetime (L80) 100000 h
On-/Off-cycles 100000
Lifetime (L90) 50000 h

Capabilities

Dimmability On-Off
With sensor No

Certificates and standards

Protection class according to IEC 61140 II
Impact strength IK08
Glow wire test 850°C
Risk group (EN 62471) RG0
Type of control gear LED operating device current-controlled
With control gear Yes
Driver failure rate (at 5,000 hrs) 1%
Input current 0.249 A
Wirethrough No
Finishing Grey RAL 7035
Housing colour Grey
Cover material Polycarbonate
Pressure valve No
Coastal proof No
Length 1580 mm
Width 63 mm
Height/depth 62 mm
Storage environment -30|60°C
Application temperature 25°C
Operating temperature -30|45°C
EAN codeEU HS CodePackagingAmountSize (L x W x H)Weight
693720960967094051190CT10.066 x 0.066 x 1.667 m1.38 KG
